Tube leakage is one of the most serious problems that can occur in a shell and tube heat exchanger. A leaking tube can allow the two process fluids to mix, contaminate the product, affect process performance, and in some applications create significant safety risks.
For this reason, preventing tube leakage should not begin only after the heat exchanger is installed. Tube material selection, tube-to-tubesheet connections, welding quality, mechanical design, inspection, and pressure testing all need to be considered during manufacturing.
Understanding the common causes of tube leakage can help plant operators and procurement teams evaluate heat exchanger quality more effectively.
A shell and tube heat exchanger is designed to keep the tube-side and shell-side fluids separated while allowing heat to pass through the tube walls.
When a tube develops a leak, this separation can be compromised.
Depending on the application, tube leakage may result in:
Cross-contamination between two fluids
Loss of product quality
Reduced heat transfer performance
Changes in operating pressure
Increased fluid consumption
Corrosion of other components
Unplanned shutdowns
Additional inspection and maintenance costs
The consequences can be particularly serious when the two sides contain corrosive, toxic, flammable, or otherwise hazardous media.
Therefore, leak prevention is an important part of both heat exchanger design and manufacturing quality control.
Tube leakage can have several causes. It is rarely related to a single factor alone.
The most common causes include:
Tube corrosion
Tube-to-tubesheet joint failure
Welding defects
Thermal stress
Tube vibration
Pressure cycling
Improper material selection
Manufacturing or installation damage
Identifying the potential failure mechanism is important because the appropriate prevention method depends on the actual operating environment.
Corrosion is one of the most common causes of tube failure.
The tube material is continuously exposed to the process fluid, and corrosion can gradually reduce the tube wall thickness. Localized corrosion, such as pitting, can be particularly difficult to detect because a relatively small area may develop significant penetration.
The risk of corrosion depends on factors such as:
Chemical composition of the fluid
Chloride concentration
Operating temperature
Fluid velocity
pH
Dissolved gases
Operating pressure
Material compatibility
Therefore, tube material should be selected according to the actual process conditions rather than based only on initial equipment cost.
Pretank offers materials including SUS304, SUS316L, SUS316Ti, Hastelloy and other options, with material selection based on fluid, pressure and temperature requirements.
The connection between the tubes and tubesheets is another critical area.
Even when the tube itself has sufficient corrosion resistance and mechanical strength, a poor tube-to-tubesheet connection can eventually result in leakage.
Depending on the design, tubes may be connected to the tubesheet using welding, expansion, or a combination of methods.
The connection needs to provide sufficient mechanical strength while maintaining reliable sealing under the expected operating conditions.
Pretank's heat exchanger manufacturing process includes tube-head welding and, where required, hydraulic expansion connections. The company states that tube-sheet and baffle holes are CNC-machined to improve dimensional accuracy and surface quality during tube installation.
Welding quality is particularly important for welded heat exchanger components.
Defects or imperfections in welds can become potential leakage paths, especially when the equipment operates under pressure or experiences repeated temperature changes.
Professional welding procedures, qualified welders, appropriate welding parameters, and inspection are therefore essential.
Pretank states that heat exchanger welding is performed according to welding procedure requirements by certified welders. Its manufacturing process also includes inspection methods such as PT and MT for specified weld areas.
The objective is not simply to produce a visually good weld, but to ensure that the weld has the required structural integrity and sealing performance.
Shell and tube heat exchangers frequently operate with fluids at different temperatures.
As the temperature changes, the shell and tubes expand and contract. If the design does not adequately accommodate differential thermal expansion, stresses can develop in the tubes, tubesheets, shell, or connections.
Repeated thermal cycles can contribute to fatigue over time.
This is one reason why the appropriate heat exchanger configuration should be selected according to the operating conditions.
For applications involving significant temperature differences, designs such as U-tube or floating-head heat exchangers may provide better accommodation of thermal expansion than a conventional fixed tube sheet arrangement. Pretank offers fixed tube sheet, U-tube, floating head and stuffing box configurations.
Fluid flowing through the shell and tube bundle can generate vibration.
If vibration becomes excessive, it may cause:
Tube wear
Fretting
Fatigue damage
Damage at tube supports
Tube-to-tubesheet problems
Baffles play an important role in supporting the tube bundle and guiding shell-side flow. Proper tube support and flow-path design can therefore help reduce the risk of vibration-related damage.
The heat exchanger should be designed with the actual fluid velocity, tube arrangement, baffle configuration, and operating conditions in mind.
A heat exchanger may not operate at one constant pressure throughout its service life.
Startup, shutdown, process changes, and repeated operating cycles can expose the equipment to pressure fluctuations.
Repeated pressure cycling can contribute to fatigue in tubes, welds, joints, and other pressure-retaining components.
For this reason, the mechanical design should consider not only the normal operating pressure but also the expected pressure conditions and operating cycles.
Selecting a tube material based only on price can create problems later.
The tube material needs to be compatible with the process fluid and suitable for the required temperature, pressure, corrosion environment, and service conditions.
For example, a material that performs well with one process fluid may not be suitable for another fluid containing chlorides or other aggressive components.
Material selection should therefore be treated as part of the overall heat exchanger design rather than as an isolated purchasing decision.
Leak detection can take place at different stages, from manufacturing inspection to operation in the plant.
Common methods include:
Visual inspection
Pressure testing
Hydrostatic testing
Air pressure testing
Air tightness testing
Leakage testing
Non-destructive testing (NDT)
In-service performance monitoring
The appropriate inspection method depends on the equipment design, applicable standards, materials, welds, and project requirements.
Non-destructive testing allows potential defects to be evaluated without damaging the component.
Depending on the applicable inspection requirements, common NDT methods include:
RT uses X-rays or gamma radiation to examine certain welds for internal discontinuities.
UT uses ultrasonic waves to detect and evaluate internal flaws or measure material thickness.
PT can help identify surface-breaking defects, particularly on suitable non-porous materials.
MT is used for detecting surface and near-surface discontinuities in suitable ferromagnetic materials.
These methods do not all detect the same types of defects. A suitable inspection plan should therefore be established according to the component, material, applicable standard, and project requirements.
Pretank's heat exchanger manufacturing process includes RT, UT, PT and MT as part of its NDT capabilities.
NDT is only part of quality control.
For equipment designed to operate under pressure, pressure and leakage testing can provide an additional verification of equipment integrity.
Depending on the project requirements, Pretank states that heat exchangers can undergo hydraulic pressure testing, air pressure testing, air tightness testing and leakage testing in accordance with the applicable requirements. The company also states that inspection and acceptance records are compiled as part of the factory documentation.
This is important for buyers because a heat exchanger should not be evaluated only by its appearance or basic dimensions. The inspection and testing documentation is also an important part of the equipment quality package.
A reliable approach to tube leakage prevention should cover the entire manufacturing process.
Consider the actual fluid composition, temperature, pressure, corrosion environment, and expected service conditions.
Tube holes, tube installation, welding, and expansion should be controlled according to the equipment design and applicable manufacturing requirements.
Proper welding procedures and qualified personnel help reduce the risk of defects in pressure-retaining components.
Tube supports, baffle arrangement, flow velocity, and tube layout should be considered together to reduce excessive vibration.
Where significant temperature differences exist, the heat exchanger configuration should be selected to accommodate expected thermal expansion.
NDT, pressure testing, air tightness testing, and leakage testing should be applied according to the applicable standards and project requirements.
When evaluating a shell and tube heat exchanger supplier, buyers should look beyond the heat transfer area and price.
Important questions include:
What materials are available for the tubes and shell?
How are tubes connected to the tubesheets?
What welding procedures are used?
Are welders properly qualified?
Which NDT methods are available?
Is hydrostatic testing performed?
Is air tightness or leakage testing required?
What inspection records will be provided?
Which design and manufacturing standards are followed?
How is material traceability handled?
These questions can help distinguish a heat exchanger designed only to meet basic specifications from one manufactured with a more comprehensive quality-control system.
Pretank manufactures fixed tube sheet, U-tube, floating head and stuffing box heat exchangers for different industrial applications. Its heat exchanger manufacturing process covers design, material selection, tube and tubesheet fabrication, welding, inspection and testing.
The company states that its heat exchangers are manufactured and inspected according to applicable industry standards, including GB/T 151, ASME, PED and EAC, depending on project requirements. It also uses SW6-2011 and PV Elite for thermal and mechanical design.
For customers purchasing heat exchangers for chemical, energy, food, pharmaceutical or other industrial applications, this integrated approach helps address both thermal performance and equipment integrity.
Tube leakage can result from corrosion, poor tube-to-tubesheet connections, welding defects, thermal stress, vibration, pressure cycling, or inappropriate material selection.
Preventing leakage therefore requires more than a final leak test. Material selection, mechanical design, welding quality, tube installation, NDT, pressure testing and leakage testing all contribute to the reliability of a shell and tube heat exchanger.
For industrial buyers, evaluating a supplier's manufacturing and inspection capabilities before purchase can help reduce the risk of leakage-related failures and unexpected maintenance.
