WST-SW-Dim
Pretank
500L - 10,000L, other volume can be customized
Availability: | |
---|---|
| Product Description
Pretank wine fermentation vessel are versatile vessels suitable for the fermentation of white wine and the storage of both red and white wines.
The tanks feature smooth surfaces and impeccably finished welds, preventing the formation of wine stone and the accumulation of impurities.
Choose between sloped flat bottoms and conical bottoms based on your preferences. The cooling jacket area can be customized to meet your specific temperature control requirements.
| Basic Configuration
Cylindrical Shell
Conical top
Slope bottom
4 legs with adjustable feet and levelling tubes
Top round manhole
Oval manhole at side
Levelling indicator
Breathing valve
Sample valve
Drainage outlet
Lifting lugs X2
Ladder rack x 1
Cooling jacket
| Product Parameter
Structure | Conical top with cylindrical shell, sloped flat bottom and single wall |
Material | SS304 |
Jacket type | / |
Insulation | / |
Surface finish | 2B/oil brushed/Internal welds to be ground,pickled&passivated |
Accessories | Manhole, cooling jacket, sampler, inlet/outlet, drainage, lifting lug, ladder rack, thermometer, liquid leveling |
OEM/ODM | Can be customized according to customers’ requirements and productions process |
Type | Capacity(L) | Shell dimension D(mm) | Total height H(mm) | Legs (N) | Cooling area (m2) |
WST1 | 1000 | Φ920*1500 | 2180 | 3 | 1.4 |
WST2 | 2000 | Φ1270*1610 | 2600 | 3 | 2.2 |
WST3 | 3000 | Φ1500*1830 | 3000 | 4 | 3 |
WST4 | 4000 | Φ1600*2000 | 3250 | 4 | 4 |
WST5 | 5000 | Φ1600*2440 | 3650 | 4 | 5 |
WST6 | 6000 | Φ1800*2440 | 3500 | 4 | 5.5 |
WST8 | 8000 | Φ1820*3050 | 4650 | 4 | 7 |
WST10 | 10000 | Φ1900*3660 | 5050 | 4 | 8.5 |
WST12 | 12000 | Φ1900*4270 | 5750 | 4 | 10 |
WST15 | 15000 | Φ2000*4880 | 5950 | 4 | 12 |
WST20 | 20000 | Φ2300*4880 | 6100 | 4 | 14 |
WST25 | 25000 | Φ2600*4880 | 6050 | 4 | 15 |
WST30 | 30000 | Φ2600*5500 | 6550 | 4/6 | 18 |
We provide turnkey engineering services,contact us with admin@prettech.cn
| Product Features
Brushed Exterior
Brushed exterior finish gives excellent appearance.
Slope or Conical Bottom
Slope bottom or conical bottom gives an easy discharging of liquid and easy to clean.
Work as Buffer
Work as buffer not only for wine but also for other sanitary liquids such as water, spirits, juice,oil,tea.
Customizable base
Except for legs supporting, mounted on concrete plinth also available for big-volume tank.
| Product Details
| Cooperation Project
| Product Description
Pretank wine fermentation vessel are versatile vessels suitable for the fermentation of white wine and the storage of both red and white wines.
The tanks feature smooth surfaces and impeccably finished welds, preventing the formation of wine stone and the accumulation of impurities.
Choose between sloped flat bottoms and conical bottoms based on your preferences. The cooling jacket area can be customized to meet your specific temperature control requirements.
| Basic Configuration
Cylindrical Shell
Conical top
Slope bottom
4 legs with adjustable feet and levelling tubes
Top round manhole
Oval manhole at side
Levelling indicator
Breathing valve
Sample valve
Drainage outlet
Lifting lugs X2
Ladder rack x 1
Cooling jacket
| Product Parameter
Structure | Conical top with cylindrical shell, sloped flat bottom and single wall |
Material | SS304 |
Jacket type | / |
Insulation | / |
Surface finish | 2B/oil brushed/Internal welds to be ground,pickled&passivated |
Accessories | Manhole, cooling jacket, sampler, inlet/outlet, drainage, lifting lug, ladder rack, thermometer, liquid leveling |
OEM/ODM | Can be customized according to customers’ requirements and productions process |
Type | Capacity(L) | Shell dimension D(mm) | Total height H(mm) | Legs (N) | Cooling area (m2) |
WST1 | 1000 | Φ920*1500 | 2180 | 3 | 1.4 |
WST2 | 2000 | Φ1270*1610 | 2600 | 3 | 2.2 |
WST3 | 3000 | Φ1500*1830 | 3000 | 4 | 3 |
WST4 | 4000 | Φ1600*2000 | 3250 | 4 | 4 |
WST5 | 5000 | Φ1600*2440 | 3650 | 4 | 5 |
WST6 | 6000 | Φ1800*2440 | 3500 | 4 | 5.5 |
WST8 | 8000 | Φ1820*3050 | 4650 | 4 | 7 |
WST10 | 10000 | Φ1900*3660 | 5050 | 4 | 8.5 |
WST12 | 12000 | Φ1900*4270 | 5750 | 4 | 10 |
WST15 | 15000 | Φ2000*4880 | 5950 | 4 | 12 |
WST20 | 20000 | Φ2300*4880 | 6100 | 4 | 14 |
WST25 | 25000 | Φ2600*4880 | 6050 | 4 | 15 |
WST30 | 30000 | Φ2600*5500 | 6550 | 4/6 | 18 |
We provide turnkey engineering services,contact us with admin@prettech.cn
| Product Features
Brushed Exterior
Brushed exterior finish gives excellent appearance.
Slope or Conical Bottom
Slope bottom or conical bottom gives an easy discharging of liquid and easy to clean.
Work as Buffer
Work as buffer not only for wine but also for other sanitary liquids such as water, spirits, juice,oil,tea.
Customizable base
Except for legs supporting, mounted on concrete plinth also available for big-volume tank.
| Product Details
| Cooperation Project
| About Company
Pretank is established in 1971, it's the largest-scale and longest-history stainless steel vessels manufacturer in China,with 4000 staff, 666,000 m㎡ floor space and US$240 million annual sales. We have the most advanced technology, R&D capability in the industry,adopt solidworks and AutoCAD to design vessels, Engaged in formulation of National Standard in designing, producing, inspection and transportation.
53-Year History in Tank Fabrication
Prettech stainless steel tanks already used in 40 classifications,gather rich experiences and precipitate skills in varied industries,win 100,000 client’s trust
Guarantee Quality
- Ensure no leaks no rust, easy cleaning.
- All tanks are over engineered and heavy-duty made, lengthen tank service life.
- Stainless steel tanks produced by automatic and laser machines, reduce labor fault.
- Each tank is strictly tested and inspected before delivery.
- We pass through ISO certificates CE, PED, API650, AS1210, AS1692, CSA, supply 2-year warranty.
Competitive Price
Scale production and automatic machines reduce cost, Pretank always perseus the most reasonable price policy to share the profits with our consumers and distributors. With same quality our price are more strong competitive.
Customize Service Free of Charge
Our bespoke tanks are tailor-made for each project, considering material, strength calculations, dimensions, fittings, and ports.We listen carefully to your needs and provide humane designs.
Lifetime Engineering Service
At pretank family, you will get lifetime engineering service! Installation service on your site, making all the AutoCAD drawings for you, completely free parts replacement in the warranty date, low cost parts supplied out of the warranty, technology support door to door, lifetime consult support.
| Processing Machinery
Pretank use advanced processing machines to fabricate our stainless steel tanks,including auto Robot welding machine,laser cutting/welding machine,CNC lathe,plasma cutting and automatic welding machines.
The machines replace labor working and minimize the human fault& tanks defects,improve tank quality, shorten construction period.
| Certificate
Over 100 patents including utility,invrention and industrial design.
Pass through ISO certificates of ISO9001/22000/ 45001, and other export certificates of CE, PED, API650, AS1210, AS1692, CSA.
| About Company
Pretank is established in 1971, it's the largest-scale and longest-history stainless steel vessels manufacturer in China,with 4000 staff, 666,000 m㎡ floor space and US$240 million annual sales. We have the most advanced technology, R&D capability in the industry,adopt solidworks and AutoCAD to design vessels, Engaged in formulation of National Standard in designing, producing, inspection and transportation.
53-Year History in Tank Fabrication
Prettech stainless steel tanks already used in 40 classifications,gather rich experiences and precipitate skills in varied industries,win 100,000 client’s trust
Guarantee Quality
- Ensure no leaks no rust, easy cleaning.
- All tanks are over engineered and heavy-duty made, lengthen tank service life.
- Stainless steel tanks produced by automatic and laser machines, reduce labor fault.
- Each tank is strictly tested and inspected before delivery.
- We pass through ISO certificates CE, PED, API650, AS1210, AS1692, CSA, supply 2-year warranty.
Competitive Price
Scale production and automatic machines reduce cost, Pretank always perseus the most reasonable price policy to share the profits with our consumers and distributors. With same quality our price are more strong competitive.
Customize Service Free of Charge
Our bespoke tanks are tailor-made for each project, considering material, strength calculations, dimensions, fittings, and ports.We listen carefully to your needs and provide humane designs.
Lifetime Engineering Service
At pretank family, you will get lifetime engineering service! Installation service on your site, making all the AutoCAD drawings for you, completely free parts replacement in the warranty date, low cost parts supplied out of the warranty, technology support door to door, lifetime consult support.
| Processing Machinery
Pretank use advanced processing machines to fabricate our stainless steel tanks,including auto Robot welding machine,laser cutting/welding machine,CNC lathe,plasma cutting and automatic welding machines.
The machines replace labor working and minimize the human fault& tanks defects,improve tank quality, shorten construction period.
| Certificate
Over 100 patents including utility,invrention and industrial design.
Pass through ISO certificates of ISO9001/22000/ 45001, and other export certificates of CE, PED, API650, AS1210, AS1692, CSA.
